OUR CARS

2017 - 2018

Technical Specification

Length/ height/ width/ wheelbase

2880 / 1225 / 1428 / 1590

Track 1195 / 1091

Car weight (approx.)

262 (kgs.)

Weight distribution  (approx.)

45/55

Suspension

double unequal length A-arm

front/double unequal length A-arm

push rod actuated rear

Tyres 20.5 x 70 x 13.0 Hoosier

Wheels Braid WINRACE A MONO.

6"x13" ET+20 8.00 116.80 934.40 4x100x50.1

Brakes 228.6mm/ 220mm brake rotors (4.5 mm thick).

AP Racing Callipers CP2505 (front)

Wilwood PS-1 (rear)

Chassis Tubular steel spaceframe

Engine   Honda CBR600F ABS 2012

Bore/stroke/cylinders/cc

67/42.5/4/599

Fuel system Electronic Fuel injection controlled by

DTAFast S60 pro ECU. Honda OEM Fuel injectors

Transmission Single 520 chain

Differential Drexler Limited Slip Differential V3 with

ramp angle adjustment

Final drive 2.75:1

2016 - 2017

Technical Specification

Length/ height/ width/ wheelbase

3000 / 705 / 13801570

Track 1295.58/1276.26

Car weight (approx.)

270 (kgs.)

Weight distribution  (approx.)

45/55

Suspension

Double unequal length A-arm

front/double unequal length A-arm,

push rod actuated rear

Tyres 20.5 x 70 x 13.0 Hoosier

Wheels Braid WINRACE A MONO.

6"x13" ET+20 8.00 116.80 934.40 4x100x50.1

Brakes 228.6mm/ 220mm brake rotors (4.5 mm thick).

AP Racing Callipers CP2505

Chassis Tubular steel spaceframe

Engine   Honda CBR600F ABS 2012

Bore/stroke/cylinders/cc

67/42.5/4/599

Fuel system PGM Fuel Injection

Transmission Single 520 chain

Differential Quaife Limited Slip QDF7ZR

Final drive 2.7:1
